7 parts in LDO Regulator ← browse all
| mpn | lcsc | description | package | jlc class | |
|---|---|---|---|---|---|
| AMS1117-3.3 Advanced Monolithic Systems | C6186 | 3.3V 1A 15V 15V Output Configuration:Positive Voltage - Supply:15V Output Voltage:3.3V Output Voltage:3.3V Output Current:1A Power Supply Rejection Ratio (PSRR):72dB@(120Hz) Voltage Dropout:1.1V@(800mA) standby current:5mA Noise:0.003%Vout Features:Short Circuit Protecti [LDO Regulator] | SOT-223 | Basic Part | |
| AP2112K-3.3TRG1 DIODES(美台) | C51118 | 3.3V 600mA 6V 6V Output Configuration:Positive Voltage - Supply:6V Output Voltage:3.3V Output Voltage:3.3V Output Current:600mA Power Supply Rejection Ratio (PSRR):65dB@(1kHz) Voltage Dropout:250mV@(600mA) standby current:55uA Noise:50uVrms Features:Enable control；Short C [LDO Regulator] | SOT-25-5 | Extended Part | |
| ME6211C33M5G-N MICRONE(南京微盟) | C82942 | 3.3V 500mA 6V 6V Output Configuration:Positive Voltage - Supply:6V Output Voltage:3.3V Output Voltage:3.3V Output Current:500mA Power Supply Rejection Ratio (PSRR):70dB@(1kHz) Voltage Dropout:120mV@(100mA) standby current:60uA Noise:50uVrms Features:Enable control；Short C [LDO Regulator] | SOT-23-5 | Extended Part | |
| RT9193-33GB RICHTEK(立锜) | C15651 | 3.3V 300mA 5.5V 5.5V Output Configuration:Positive Voltage - Supply:5.5V Output Voltage:3.3V Output Voltage:3.3V Output Current:300mA Power Supply Rejection Ratio (PSRR):-50dB@(10kHz) Voltage Dropout:220mV@(300mA) standby current:90uA Noise:100uVrms Features:Enable control；Ov [LDO Regulator] | SOT-23-5 | Extended Part | |
| TLV75533PDBVR TI(德州仪器) | C404027 | 3.3V 500mA 5.5V 5.5V Output Configuration:Positive Voltage - Supply:5.5V Output Voltage:3.3V Output Voltage:3.3V Output Current:500mA Power Supply Rejection Ratio (PSRR):46dB@(100kHz) Voltage Dropout:238mV@(500mA) standby current:25uA Noise:71.5uVrms Features:Enable control；O [LDO Regulator] | SOT-23-5 | Extended Part | |
| XC6206P332MR-G Torex | C5446 | 3.3V 200mA ultra-low-Iq 1uA LDO (replaces TPS7A16) [LDO Regulator] | SOT-23-3_L2.9-W1.6-P1.90-LS2.8-BR | Basic Part | |
| HT7333-A-EV — | C28642151 | HT7333-A-EV Output Type:Fixed Maximum Input Voltage:24V Output Voltage:3.3V Output Voltage:3.3V Output Current:300mA Output Polarity:Positive electrode [LDO Regulator] | SOT-89 | Extended Part |
