AP2112K-3.3TRG1

Identity

• Manufacturer: DIODES(美台)
• Model / MPN: AP2112K-3.3TRG1
• LCSC: C51118
• Category: ldo-regulator
• Description: 3.3V 600mA 6V 6V Output Configuration:Positive Voltage - Supply:6V Output Voltage:3.3V Output Voltage:3.3V Output Current:600mA Power Supply Rejection Ratio (PSRR):65dB@(1kHz) Voltage Dropout:250mV@(600mA) standby current:55uA Noise:50uVrms Features:Enable control；Short C
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• Not captured yet.

Package And Footprint

• Package / footprint name: SOT-25-5
• Pin count: 5
• EasyEDA symbol UUID: d2326f3191bc4720b49f988bd8aad5da
• EasyEDA footprint UUID: 495a893cd5c14fc0a936ab2f2b7023a5
• EasyEDA device UUID: 8c72fdff8032447e8704660d377171f6
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: EasyEDA property: 6V.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified common IoT basics seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://item.szlcsc.com/datasheet/AP2112K-3.3TRG1/52131.html
• Product URL: https://item.szlcsc.com/datasheet/AP2112K-3.3TRG1/52131.html
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: power-tree designs when ratings and layout constraints fit
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category ldo-regulator, interfaces none captured, package SOT-25-5, and EasyEDA footprint UUID 495a893cd5c14fc0a936ab2f2b7023a5.
