TMP102AIDRLR

Identity

Manufacturer: TI(德州仪器)
Model / MPN: TMP102AIDRLR
LCSC: C99269
Category: temperature-sensor
Description: Low-power digital temperature sensor with SMBus and 2-wire serial interface, ±0.5°C, 1.4V~~3.6V, I2C, -40°C~~+125°C, 1uA standby, 26ms.
Source: EasyEDA/JLC verified common component seed
Project designators: Not project-specific
Project quantity per board: Not project-specific

Capabilities

i2c: interface

Package And Footprint

Package / footprint name: SOT-563
Pin count: Unknown
EasyEDA symbol UUID: cc9eceb51f904a3b932de4280711e62f
EasyEDA footprint UUID: 473d8565d9dc4b5ba40163e7f6b19cf0
EasyEDA device UUID: 301076a0c60a4946891445aec913adcb
EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

Active current: Not characterized in seed; extract active current from datasheet tables.
Sleep / standby current: EasyEDA property: 1uA.
Supply rails: EasyEDA property: 1.4V~3.6V.
Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

JLC class: Extended Part
JLC note / assembly basis: EasyEDA/JLC verified common environment, motion, light, proximity, and temperature sensor seed
Assembly status: jlc_extended
Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

Datasheet / product URL: https://www.ti.com/cn/lit/gpn/tmp102
Product URL: https://www.ti.com/cn/lit/gpn/tmp102
Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

Good for: board temperature, enclosure temperature, thermal alarms, compensation inputs, and 1-Wire or I2C temperature telemetry
Avoid when: Not captured yet.
Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
Equivalent search hints: match category temperature-sensor, interfaces i2c, package SOT-563, and EasyEDA footprint UUID 473d8565d9dc4b5ba40163e7f6b19cf0.
