ADXL345BCCZ-RL7
Identity
- Manufacturer: ADI(亚德诺)
- Model / MPN: ADXL345BCCZ-RL7
- LCSC: C9667
- Category: accelerometer
- Description: 3-axis digital accelerometer, ±2 G/±4 G/±8 G/±16 G
- Source: EasyEDA/JLC verified common component seed
- Project designators: Not project-specific
- Project quantity per board: Not project-specific
Capabilities
- i2c: interface
- spi: interface
Package And Footprint
- Package / footprint name: LGA-14(3x5)
- Pin count: 14
- EasyEDA symbol UUID: 7ee4588b4d6545bbae4c612020444219
- EasyEDA footprint UUID: c7d5b0a17c6e463290ba16bdcdd1c0cc
- EasyEDA device UUID: ab6ad91865a64407a877437c625e810e
- EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87
Power And Operating Modes
- Active current: Not characterized in seed; extract active current from datasheet tables.
- Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
- Supply rails: Not characterized in seed; capture allowed supply rail range from datasheet.
- Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.
Procurement Classification
- JLC class: Extended Part
- JLC note / assembly basis: EasyEDA/JLC verified common environment, motion, light, proximity, and temperature sensor seed
- Assembly status: jlc_extended
- Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
- Live stock: intentionally not stored as durable selection data; refresh externally before ordering.
Datasheet And Links
- Datasheet / product URL: https://atta.szlcsc.com/upload/public/pdf/source/20170717/C9667_1500286943358822273.pdf
- Product URL: https://atta.szlcsc.com/upload/public/pdf/source/20170717/C9667_1500286943358822273.pdf
- Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.
Selection Notes
- Good for: motion wake, tilt/orientation, vibration monitoring, impact detection, tap detection, and low-power activity sensing
- Avoid when: Not captured yet.
- Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
- Equivalent search hints: match category
accelerometer, interfaces i2c, spi, packageLGA-14(3x5), and EasyEDA footprint UUIDc7d5b0a17c6e463290ba16bdcdd1c0cc.
