M7

Identity

• Manufacturer: MDD(辰达半导体)
• Model / MPN: M7
• LCSC: C95872
• Category: rectifier-diode
• Description: 1kV 1A Diode Configuration:Standalone Voltage - Forward(Vf@If):1.1V@1A Voltage - DC Reverse(Vr):1kV Current - Rectified:1A Reverse Leakage Current (Ir):5uA@1kV Non-Repetitive Peak Forward Surge Current:30A Operating Junction Temperature Range:-55℃~+150℃ Operatin
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• Not captured yet.

Package And Footprint

• Package / footprint name: SMA(DO-214AC)
• Pin count: Unknown
• EasyEDA symbol UUID: d62a8b1134674750a60a017f640f4351
• EasyEDA footprint UUID: 62b9c7ac34c94f47b6b3328a62c4bfa6
• EasyEDA device UUID: 590c967f6e1b4c1b83917b05751b5999
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Passive part; no quiescent current.
• Sleep / standby current: Passive part; no quiescent current.
• Supply rails: 1kV
• Notes: Ratings are seeded from EasyEDA/LCSC properties when present; verify against datasheet for final design.

Procurement Classification

• JLC class: Basic Part
• JLC note / assembly basis: EasyEDA/JLC verified common board support, timing, EMI, and protection seed
• Assembly status: jlc_basic
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://item.szlcsc.com/datasheet/M7/97076.html
• Product URL: https://item.szlcsc.com/datasheet/M7/97076.html
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category rectifier-diode, interfaces none captured, package SMA(DO-214AC), and EasyEDA footprint UUID 62b9c7ac34c94f47b6b3328a62c4bfa6.
