NR8040T100M

Identity

Manufacturer: TAIYO YUDEN(太诱)
Model / MPN: NR8040T100M
LCSC: C92945
Category: power-inductor
Description: 10uH ±20% 3.4A 10uH ±20% Inductance:10uH Tolerance:±20% Tolerance:±20% Current Rating:3.1A Current - Saturation(Isat):3.4A DC Resistance(DCR):44.2mΩ Type:- Ratings:-
Source: EasyEDA/JLC verified common component seed
Project designators: Not project-specific
Project quantity per board: Not project-specific

Capabilities

Not captured yet.

Package And Footprint

Package / footprint name: SMD,8x8mm
Pin count: Unknown
EasyEDA symbol UUID: a0e9caa0bc974a3bad8e367c70b6d33f
EasyEDA footprint UUID: 591607ced74542bc9cb2b0d6e9f981bd
EasyEDA device UUID: ce3ee5daa9f24eec9e633c677ca12164
EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

Active current: Passive part; no quiescent current.
Sleep / standby current: Passive part; no quiescent current.
Supply rails: Application-defined.
Notes: Ratings are seeded from EasyEDA/LCSC properties when present; verify against datasheet for final design.

Procurement Classification

JLC class: Extended Part
JLC note / assembly basis: EasyEDA/JLC verified common board support, timing, EMI, and protection seed
Assembly status: jlc_extended
Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

Datasheet / product URL: https://item.szlcsc.com/datasheet/NR8040T100M/94139.html
Product URL: https://item.szlcsc.com/datasheet/NR8040T100M/94139.html
Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
Avoid when: Not captured yet.
Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
Equivalent search hints: match category power-inductor, interfaces none captured, package SMD,8x8mm, and EasyEDA footprint UUID 591607ced74542bc9cb2b0d6e9f981bd.
