ATGM336H-5N31

Identity

Manufacturer: 杭州中科微
Model / MPN: ATGM336H-5N31
LCSC: C90770
Category: gnss-module
Description: ATGM336H-5N31 BDS/GNSS module; UART/I2C; 2.7V~3.6V; BDS/GPS; 25mA@3.3V; sensitivity -148dBm; accuracy 2.5m; TTFF 35s
Source: EasyEDA/JLC verified common component seed
Project designators: Not project-specific
Project quantity per board: Not project-specific

Capabilities

uart: interface
i2c: interface

Package And Footprint

Package / footprint name: SMD,10.1x9.7mm
Pin count: Unknown
EasyEDA symbol UUID: b9e4d99381fc47d191fff6d95b8ccd9a
EasyEDA footprint UUID: 1ab632ea7e2d46bca890291e52012915
EasyEDA device UUID: 3856c5065c5241769093a229ced01a92
EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

Active current: EasyEDA property: 25mA@3.3V.
Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
Supply rails: EasyEDA property: 2.7V~3.6V.
Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

JLC class: Extended Part
JLC note / assembly basis: EasyEDA/JLC verified common connectivity, positioning, and RF interface seed
Assembly status: jlc_extended
Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

Datasheet / product URL: https://item.szlcsc.com/datasheet/ATGM336H-5N31/91958.html
Product URL: https://item.szlcsc.com/datasheet/ATGM336H-5N31/91958.html
Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
Avoid when: Not captured yet.
Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
Equivalent search hints: match category gnss-module, interfaces uart, i2c, package SMD,10.1x9.7mm, and EasyEDA footprint UUID 1ab632ea7e2d46bca890291e52012915.
