SP3485EN-L/TR
Identity
- Manufacturer: MaxLinear(迈凌)
- Model / MPN: SP3485EN-L/TR
- LCSC: C8963
- Category: rs485-transceiver
- Description: SP3485 3.3V low-power half-duplex RS-485 transceiver, 1 driver, 1 receiver, 10Mbps data rate, 32 nodes, -40°C~+85°C.
- Source: EasyEDA/JLC verified common component seed
- Project designators: Not project-specific
- Project quantity per board: Not project-specific
Capabilities
- uart: interface
- rs485: interface
Package And Footprint
- Package / footprint name: SOIC-8
- Pin count: 8
- EasyEDA symbol UUID: d79d354c075448999126248ba9f7e8dd
- EasyEDA footprint UUID: a21abe53057c4752a13d1e8ec2866de7
- EasyEDA device UUID: 69d33240c27d4d8da21600b8e1093b78
- EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87
Power And Operating Modes
- Active current: Not characterized in seed; extract active current from datasheet tables.
- Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
- Supply rails: EasyEDA property: 3.3V.
- Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.
Procurement Classification
- JLC class: Basic Part
- JLC note / assembly basis: EasyEDA/JLC verified common IoT sensors, storage, and communications seed
- Assembly status: jlc_basic
- Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
- Live stock: intentionally not stored as durable selection data; refresh externally before ordering.
Datasheet And Links
- Datasheet / product URL: https://item.szlcsc.com/datasheet/SP3485EN-L%252FTR/9482.html
- Product URL: https://item.szlcsc.com/datasheet/SP3485EN-L%252FTR/9482.html
- Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.
Selection Notes
- Good for: Modbus, industrial UART links, long cable serial links, and half-duplex RS-485 buses
- Avoid when: Not captured yet.
- Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
- Equivalent search hints: match category
rs485-transceiver, interfaces uart, rs485, packageSOIC-8, and EasyEDA footprint UUIDa21abe53057c4752a13d1e8ec2866de7.
