ENC28J60/SS
Identity
- Manufacturer: MICROCHIP(美国微芯)
- Model / MPN: ENC28J60/SS
- LCSC: C8961
- Category: ethernet-controller
- Description: ENC28J60/SS 3.3V SPI Number of Channels:1 Interface:SPI Voltage - Supply:3.3V Voltage - Supply:3.3V Current - Supply:160mA Operating Temperature:-40℃
+85℃ Operating Temperature:-40℃+85℃ - Source: EasyEDA/JLC verified common component seed
- Project designators: Not project-specific
- Project quantity per board: Not project-specific
Capabilities
- spi: interface
- ethernet: interface
Package And Footprint
- Package / footprint name: SSOP-28-208mil
- Pin count: 28
- EasyEDA symbol UUID: 2060a0fe66a04cdc90e94283a828859e
- EasyEDA footprint UUID: fbea7c851c5f443f9c72449091c36387
- EasyEDA device UUID: 7525abd161664723a4a1f1b8a8a7e963
- EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87
Power And Operating Modes
- Active current: EasyEDA property: 160mA.
- Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
- Supply rails: EasyEDA property: 3.3V.
- Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.
Procurement Classification
- JLC class: Extended Part
- JLC note / assembly basis: EasyEDA/JLC verified common connectivity, positioning, and RF interface seed
- Assembly status: jlc_extended
- Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
- Live stock: intentionally not stored as durable selection data; refresh externally before ordering.
Datasheet And Links
- Datasheet / product URL: https://item.szlcsc.com/datasheet/ENC28J60%252FSS/9480.html
- Product URL: https://item.szlcsc.com/datasheet/ENC28J60%252FSS/9480.html
- Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.
Selection Notes
- Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
- Avoid when: Not captured yet.
- Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
- Equivalent search hints: match category
ethernet-controller, interfaces spi, ethernet, packageSSOP-28-208mil, and EasyEDA footprint UUIDfbea7c851c5f443f9c72449091c36387.
