DS2431Q+T&R

Identity

• Manufacturer: ADI(亚德诺)/MAXIM(美信)
• Model / MPN: DS2431Q+T&R
• LCSC: C879661
• Category: secure-eeprom
• Description: 1024-bit 1-Wire EEPROM, 2.8V~5.25V, Single bus, Memory Size:1Kbit, Tw:10ms, TDR:40 Years, endurance 200,000 cycles
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• 1-wire: interface

Package And Footprint

• Package / footprint name: TDFN-6-EP(3x3)
• Pin count: 6
• EasyEDA symbol UUID: cf4c91bf6908400fab8a52d31b8fd73e
• EasyEDA footprint UUID: 206b415751854605b13bc549a6f883e3
• EasyEDA device UUID: 3049c9067ddf46bbac668b72c310d3d7
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: EasyEDA property: 2.8V~5.25V.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified common memory, timing, storage, and security seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://item.szlcsc.com/datasheet/DS2431Q%252BT%2526R/940513.html
• Product URL: https://item.szlcsc.com/datasheet/DS2431Q%252BT%2526R/940513.html
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: device identity, secure boot support, anti-cloning, key storage, certificate authentication, and 1-Wire or I2C authenticators
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category secure-eeprom, interfaces 1-wire, package TDFN-6-EP(3x3), and EasyEDA footprint UUID 206b415751854605b13bc549a6f883e3.
