B560C-13-F

Identity

• Manufacturer: Texas Instruments
• Model / MPN: B560C-13-F
• LCSC: C85100
• Category: buck-converter
• Description: TPS54360 buck catch diode (SW to GND) - TI reference design part 60V/5A Schottky
• Source: Fleet telematics BOM-VERIFIED.csv
• Project designators: D4
• Project quantity per board: 1

Capabilities

• Not captured yet.

Package And Footprint

• Package / footprint name: SMC_L7.1-W6.2-LS8.1-RD
• Pin count: Unknown
• EasyEDA symbol UUID: Not verified
• EasyEDA footprint UUID: Not verified
• EasyEDA device UUID: 3de8065d4cb949c6988dd966b486f501
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed.
• Sleep / standby current: Not characterized in seed.
• Supply rails: Not characterized in seed.
• Notes: Capture rail limits, quiescent current, and enabled/disabled states when relevant.

Procurement Classification

• JLC class: Basic Part
• JLC note / assembly basis: Standard
• Assembly status: jlc_basic
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://www.ti.com/lit/ds/symlink/tps54360.pdf
• Product URL: https://www.ti.com/lit/ds/symlink/tps54360.pdf
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: power-tree designs when ratings and layout constraints fit
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category buck-converter, interfaces none captured, package SMC_L7.1-W6.2-LS8.1-RD, and EasyEDA footprint UUID unknown.

Search Keywords

seed:fleet-telematics, source:bom-verified, buck-converter, jlc_basic, jlc-note:standard
