DRV8825PWPR

Identity

• Manufacturer: TI(德州仪器)
• Model / MPN: DRV8825PWPR
• LCSC: C81582
• Category: stepper-driver
• Description: Stepper motor driver, STEP/DIR, 2.5A output, 8.2V~45V motor drive voltage, 2 H-bridges, bipolar driver, 32 step resolution.
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• gpio: interface

Package And Footprint

• Package / footprint name: HTSSOP-28-EP
• Pin count: Unknown
• EasyEDA symbol UUID: 3e50d80e5a654141ad1054074dbfec94
• EasyEDA footprint UUID: ffec25eacf024547992563f36b3c4fc7
• EasyEDA device UUID: 9714cca7bc32460fb633047e4f7c7a31
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: Not characterized in seed; capture allowed supply rail range from datasheet.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified common drivers, isolation, and actuation seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://www.ti.com/cn/lit/gpn/drv8825
• Product URL: https://www.ti.com/cn/lit/gpn/drv8825
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category stepper-driver, interfaces gpio, package HTSSOP-28-EP, and EasyEDA footprint UUID ffec25eacf024547992563f36b3c4fc7.
