XB5353A

Identity

Manufacturer: xysemi(赛芯微)
Model / MPN: XB5353A
LCSC: C80628
Category: battery-protection
Description: XB5353A single-cell Li-ion/polymer battery protection IC; 2V~~6V; saturation 4.3V; end-off 2.4V; 1 lithium cell; -40°C~~+85°C
Source: EasyEDA/JLC verified common component seed
Project designators: Not project-specific
Project quantity per board: Not project-specific

Capabilities

Not captured yet.

Package And Footprint

Package / footprint name: SOT-23-5
Pin count: 5
EasyEDA symbol UUID: 6cd24084ddf444a993f982265f6325df
EasyEDA footprint UUID: 3962fa5424e54dde8cfd30751ab1c7e4
EasyEDA device UUID: 139aed8ae54448cba8e2036fa95db0cf
EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

Active current: Not characterized in seed; extract active current from datasheet tables.
Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
Supply rails: EasyEDA property: 2V~6V.
Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

JLC class: Extended Part
JLC note / assembly basis: EasyEDA/JLC verified common battery management, USB-C power, and power-path seed
Assembly status: jlc_extended
Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

Datasheet / product URL: https://item.szlcsc.com/datasheet/XB5353A/81778.html
Product URL: https://item.szlcsc.com/datasheet/XB5353A/81778.html
Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
Avoid when: Not captured yet.
Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
Equivalent search hints: match category battery-protection, interfaces none captured, package SOT-23-5, and EasyEDA footprint UUID 3962fa5424e54dde8cfd30751ab1c7e4.
