PEC11R-4230F-S0024

Identity

• Manufacturer: BOURNS
• Model / MPN: PEC11R-4230F-S0024
• LCSC: C7435302
• Category: rotary-encoder
• Description: 12mm incremental encoder, 24/24 detents/pulses, Two-phase output, Straight, 10mA, 5V, -30°C~+70°C
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• gpio: interface

Package And Footprint

• Package / footprint name: 插件
• Pin count: Unknown
• EasyEDA symbol UUID: d34790aeef2b428cb4b2a40bec0d77c7
• EasyEDA footprint UUID: dac7f1f639124ed8a498b961ee827395
• EasyEDA device UUID: 723b3229c75c44c2a507505692435f80
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: Not characterized in seed; capture allowed supply rail range from datasheet.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified common connector, HMI, and mechanical interface seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://item.szlcsc.com/datasheet/PEC11R-4230F-S0024/8450532.html
• Product URL: https://item.szlcsc.com/datasheet/PEC11R-4230F-S0024/8450532.html
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category rotary-encoder, interfaces gpio, package 插件, and EasyEDA footprint UUID dac7f1f639124ed8a498b961ee827395.
