SK6812MINI-C

Identity

Manufacturer: 欧思科光电
Model / MPN: SK6812MINI-C
LCSC: C7423117
Category: addressable-led
Description: SK6812MINI-C 3.7V~~5.5V Wavelength:R:615nm~~625nm；B:460nm~~470nm；G:520nm~~530nm Luminous Intensity:B:160mcd~~320mcd；R:280mcd~~515mcd；G:815mcd~~1275mcd Fixed-Frequency Pwm Mode:1kHz Voltage - Supply:3.7V~~5.5V Voltage - Supply:3.7V~5.5V Quiescent Current:0.65mA ESD Withstand Voltage:200
Source: EasyEDA/JLC verified common component seed
Project designators: Not project-specific
Project quantity per board: Not project-specific

Capabilities

gpio: interface

Package And Footprint

Package / footprint name: SMD-4P,3.7x3.5mm
Pin count: 4
EasyEDA symbol UUID: 0e2f14cec44f41f4b6d4f0eea250b4b1
EasyEDA footprint UUID: f561853f450348518338a579c89e27ed
EasyEDA device UUID: 5705df8099004f46a7147e16098cfc6f
EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

Active current: Not characterized in seed; extract active current from datasheet tables.
Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
Supply rails: EasyEDA property: 3.7V~5.5V.
Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

JLC class: Extended Part
JLC note / assembly basis: EasyEDA/JLC verified common board IO, power entry, and indicator expansion seed
Assembly status: jlc_extended
Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

Datasheet / product URL: https://item.szlcsc.com/datasheet/SK6812MINI-C/8407590.html
Product URL: https://item.szlcsc.com/datasheet/SK6812MINI-C/8407590.html
Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
Avoid when: Not captured yet.
Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
Equivalent search hints: match category addressable-led, interfaces gpio, package SMD-4P,3.7x3.5mm, and EasyEDA footprint UUID f561853f450348518338a579c89e27ed.
