TPIC6B595DWR

Identity

• Manufacturer: TI(德州仪器)
• Model / MPN: TPIC6B595DWR
• LCSC: C7094
• Category: power-shift-register
• Description: Open-drain 8-bit serial-to-serial or parallel shift register, 4.5V5.5V supply, 1 element, TPIC series, -40°C+125°C.
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• spi: interface
• gpio: interface

Package And Footprint

• Package / footprint name: SOIC-20-300mil
• Pin count: 20
• EasyEDA symbol UUID: a61844c1906e487784db091f8e4ffab0
• EasyEDA footprint UUID: 6fcda34b06e34a3bb735d06de19f015b
• EasyEDA device UUID: bbdfe7aa8a334c0db58f94289067ab50
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: EasyEDA property: 4.5V~5.5V.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified common drivers, isolation, and actuation seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://www.ti.com/cn/lit/gpn/tpic6b595
• Product URL: https://www.ti.com/cn/lit/gpn/tpic6b595
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category power-shift-register, interfaces spi, gpio, package SOIC-20-300mil, and EasyEDA footprint UUID 6fcda34b06e34a3bb735d06de19f015b.
