NRF24L01-REEL7

Identity

• Manufacturer: NORDIC
• Model / MPN: NRF24L01-REEL7
• LCSC: C7015539
• Category: wireless-transceiver
• Description: Single-chip 2.4GHz transceiver, SPI, 1.9V3.6V, 2.4GHz2.525GHz, ISM/IoT, 0dBm, 2Mbps, 11.3mA TX, -82dBm sensitivity.
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• spi: interface

Package And Footprint

• Package / footprint name: QFN-20(4x4)
• Pin count: 20
• EasyEDA symbol UUID: 08acbe8ce4fa4776b67afb939baf74cd
• EasyEDA footprint UUID: 8fea41729f79467a8cd5be5a346d21bc
• EasyEDA device UUID: 6bc46609eca940fb87dcc08aedb909d9
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: EasyEDA property: 12.3mA.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: EasyEDA property: 1.9V~3.6V.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified common IoT sensors, storage, and communications seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://item.szlcsc.com/datasheet/NRF24L01-REEL7/7981807.html
• Product URL: https://item.szlcsc.com/datasheet/NRF24L01-REEL7/7981807.html
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category wireless-transceiver, interfaces spi, package QFN-20(4x4), and EasyEDA footprint UUID 8fea41729f79467a8cd5be5a346d21bc.
