HFD4/5-SR

Identity

• Manufacturer: HF(宏发)
• Model / MPN: HFD4/5-SR
• LCSC: C64399
• Category: signal-relay
• Description: Ultra-small 5V DPDT relay, 2 Form C/2C, 8 pins, 1A@30VDC/300mA@125VAC, 250V AC/220V DC max, 140mW coil, 178Ω, 2A max
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• gpio: interface

Package And Footprint

• Package / footprint name: SMD,10x6.5mm
• Pin count: Unknown
• EasyEDA symbol UUID: 3adc6a42fd8448b1bcee2990e1ed8717
• EasyEDA footprint UUID: 8f4578d0ed1f46c5b26c87c14afd93a4
• EasyEDA device UUID: b5671b84684c42158d01ab010f9ef614
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: Not characterized in seed; capture allowed supply rail range from datasheet.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified common drivers, isolation, and actuation seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://item.szlcsc.com/datasheet/HFD4%252F5-SR/65466.html
• Product URL: https://item.szlcsc.com/datasheet/HFD4%252F5-SR/65466.html
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category signal-relay, interfaces gpio, package SMD,10x6.5mm, and EasyEDA footprint UUID 8f4578d0ed1f46c5b26c87c14afd93a4.
