MCP2003B-E/MC

Identity

• Manufacturer: MICROCHIP(美国微芯)
• Model / MPN: MCP2003B-E/MC
• LCSC: C635010
• Category: lin-transceiver
• Description: LIN transceiver, 5.5V30V supply, -40°C+125°C.
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• lin: interface

Package And Footprint

• Package / footprint name: DFN-8-EP(2x3)
• Pin count: 8
• EasyEDA symbol UUID: f6fbb5f6437d409fa5f19a3ebab96962
• EasyEDA footprint UUID: 006d7aa397484b0b8270ab1c71d91837
• EasyEDA device UUID: 0f148664f1f646888e131134efff6396
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: EasyEDA property: 5.5V~30V.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified automotive CAN and LIN transceiver seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://item.szlcsc.com/datasheet/MCP2003B-E%252FMC/664687.html
• Product URL: https://item.szlcsc.com/datasheet/MCP2003B-E%252FMC/664687.html
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category lin-transceiver, interfaces lin, package DFN-8-EP(2x3), and EasyEDA footprint UUID 006d7aa397484b0b8270ab1c71d91837.
