NEO-M8N-0

Identity

• Manufacturer: U-BLOX(优北罗)
• Model / MPN: NEO-M8N-0
• LCSC: C6330769
• Category: gnss-module
• Description: NEO-M8N-0 1.65V3.6V UART；I2C；USB；SPI GNSS Type:Galileo；GLONASS；GPS；BeiDou Interface:UART；I2C；USB；SPI Voltage - Supply:1.65V3.6V Voltage - Supply:1.65V3.6V Sensitivity:-167dBm Sensitivity:-167dBm Operating Temperature:-40℃+85℃ Operating Temperature:-40℃~+85℃
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• uart: interface
• i2c: interface
• usb: interface
• spi: interface

Package And Footprint

• Package / footprint name: SMD-24P
• Pin count: 24
• EasyEDA symbol UUID: 2551358fdbf34a3e8ed2abab14e58331
• EasyEDA footprint UUID: db46848a94e64e17bc0b96b6d944ebaa
• EasyEDA device UUID: c072ba579e0a4f6c9165fae462a2fd53
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: EasyEDA property: 1.65V~3.6V.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified common connectivity, positioning, and RF interface seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://item.szlcsc.com/datasheet/NEO-M8N-0/7278948.html
• Product URL: https://item.szlcsc.com/datasheet/NEO-M8N-0/7278948.html
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category gnss-module, interfaces uart, i2c, usb, spi, package SMD-24P, and EasyEDA footprint UUID db46848a94e64e17bc0b96b6d944ebaa.
