MCP2518FDT-E/SL

Identity

Manufacturer: MICROCHIP(美国微芯)
Model / MPN: MCP2518FDT-E/SL
LCSC: C626758
Category: can-controller
Description: External CAN-FDController with SPI interface, 8Mbps data rate, 20mA supply, 2.7V~~5.5V supply, -40°C~~+125°C.
Source: EasyEDA/JLC verified common component seed
Project designators: Not project-specific
Project quantity per board: Not project-specific

Capabilities

spi: interface

Package And Footprint

Package / footprint name: SOIC-14
Pin count: 14
EasyEDA symbol UUID: 35dbdb70f4ca47f392f0a3f7a8a9a397
EasyEDA footprint UUID: ffc76db8ffa142c1a7872c93f2ae0661
EasyEDA device UUID: 2b3eaff98c6446ada93ac26ec8b95d27
EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

Active current: EasyEDA property: 20mA.
Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
Supply rails: EasyEDA property: 2.7V~5.5V.
Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

JLC class: Extended Part
JLC note / assembly basis: EasyEDA/JLC verified second-source/alternate seed for IC categories that only had one option
Assembly status: jlc_extended
Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

Datasheet / product URL: https://item.szlcsc.com/datasheet/MCP2518FDT-E%252FSL/656665.html
Product URL: https://item.szlcsc.com/datasheet/MCP2518FDT-E%252FSL/656665.html
Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

Good for: adding SPI CAN capability to MCUs that do not include an integrated CAN controller
Avoid when: Not captured yet.
Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
Equivalent search hints: match category can-controller, interfaces spi, package SOIC-14, and EasyEDA footprint UUID ffc76db8ffa142c1a7872c93f2ae0661.
