IP2721

Identity

Manufacturer: INJOINIC(英集芯)
Model / MPN: IP2721
LCSC: C603176
Category: usb-pd-phy
Description: USB TYPEC/PD2.0/PD3.0 physical-layer IC
Source: EasyEDA/JLC verified common component seed
Project designators: Not project-specific
Project quantity per board: Not project-specific

Capabilities

usb: interface

Package And Footprint

Package / footprint name: TSSOP-16
Pin count: 16
EasyEDA symbol UUID: 5526f92b33994aaab74cbdbc4bd2682f
EasyEDA footprint UUID: a11950ceac50438289ff689a35fd9574
EasyEDA device UUID: d29d8ffc125c431abe06bf93d27cfeca
EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

Active current: Not characterized in seed; extract active current from datasheet tables.
Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
Supply rails: Not characterized in seed; capture allowed supply rail range from datasheet.
Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

JLC class: Extended Part
JLC note / assembly basis: EasyEDA/JLC verified common battery management, USB-C power, and power-path seed
Assembly status: jlc_extended
Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

Datasheet / product URL: https://item.szlcsc.com/datasheet/IP2721/634297.html
Product URL: https://item.szlcsc.com/datasheet/IP2721/634297.html
Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
Avoid when: Not captured yet.
Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
Equivalent search hints: match category usb-pd-phy, interfaces usb, package TSSOP-16, and EasyEDA footprint UUID a11950ceac50438289ff689a35fd9574.
