DF40C(2.0)-30DS-0.4V(51)

Identity

Manufacturer: HRS(广濑)
Model / MPN: DF40C(2.0)-30DS-0.4V(51)
LCSC: C597933
Category: board-to-board-connector
Description: 30P 0.4mm vertical SMT board-to-board connector, 2 rows, 300mA, Slot Type Butting, gold plating, -35°C~+85°C
Source: EasyEDA/JLC verified common component seed
Project designators: Not project-specific
Project quantity per board: Not project-specific

Capabilities

mezzanine: interface

Package And Footprint

Package / footprint name: SMD,P=0.4mm
Pin count: Unknown
EasyEDA symbol UUID: 260d0526216f4946b1e46f88386ca746
EasyEDA footprint UUID: 5211b7ec14884b56bd5a57ec72ed0b33
EasyEDA device UUID: d8108279cc824b8f90995fd17b2555a2
EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

Active current: Passive part; no quiescent current.
Sleep / standby current: Passive part; no quiescent current.
Supply rails: Application-defined.
Notes: Ratings are seeded from EasyEDA/LCSC properties when present; verify against datasheet for final design.

Procurement Classification

JLC class: Extended Part
JLC note / assembly basis: EasyEDA/JLC verified common debug headers, FPC/mezzanine connectors, field wiring terminals, and fuse seed
Assembly status: jlc_extended
Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

Datasheet / product URL: https://item.szlcsc.com/datasheet/DF40C(2.0)-30DS-0.4V(51)/626549.html
Product URL: https://item.szlcsc.com/datasheet/DF40C(2.0)-30DS-0.4V(51)/626549.html
Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

Good for: mezzanine stacking, daughtercards, radio/modem modules, display boards, and compact board-to-board expansion
Avoid when: Not captured yet.
Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
Equivalent search hints: match category board-to-board-connector, interfaces mezzanine, package SMD,P=0.4mm, and EasyEDA footprint UUID 5211b7ec14884b56bd5a57ec72ed0b33.
