PTVS36VP1UP,115

Identity

Manufacturer: Nexperia(安世)
Model / MPN: PTVS36VP1UP,115
LCSC: C553416
Category: tvs-diode
Description: Unidirectional TVS diode, 36V Vrwm, 58.1V clamp, 10.3A Ipp, 600W Ppp, 40V breakdown, 100nA leakage, -55°C~+150°C.
Source: EasyEDA/JLC verified common component seed
Project designators: Not project-specific
Project quantity per board: Not project-specific

Capabilities

Not captured yet.

Package And Footprint

Package / footprint name: SOD-128
Pin count: Unknown
EasyEDA symbol UUID: 4e54b89c8b9542f5b7e8419cb0ea0b55
EasyEDA footprint UUID: cb676080a8d14051bf67adefdc4082f9
EasyEDA device UUID: 728bbcae2f2d4906a6a34ad1fcc0bc15
EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

Active current: Passive part; no quiescent current.
Sleep / standby current: Passive part; no quiescent current.
Supply rails: Application-defined.
Notes: Ratings are seeded from EasyEDA/LCSC properties when present; verify against datasheet for final design.

Procurement Classification

JLC class: Extended Part
JLC note / assembly basis: EasyEDA/JLC verified automotive load-dump and transient input protection seed
Assembly status: jlc_extended
Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

Datasheet / product URL: https://item.szlcsc.com/datasheet/PTVS36VP1UP%252C115/574423.html
Product URL: https://item.szlcsc.com/datasheet/PTVS36VP1UP%252C115/574423.html
Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
Avoid when: Not captured yet.
Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
Equivalent search hints: match category tvs-diode, interfaces none captured, package SOD-128, and EasyEDA footprint UUID cb676080a8d14051bf67adefdc4082f9.
