BQ24075TRGTR

Identity

• Manufacturer: TI(德州仪器)
• Model / MPN: BQ24075TRGTR
• LCSC: C544783
• Category: battery-charger
• Description: Standalone 1-cell 1.5A linear battery charger with power path and voltage-based TS, 4.35V~6.4V, 4.2V saturation, 3V end-off.
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• Not captured yet.

Package And Footprint

• Package / footprint name: VQFN-16-EP(3x3)
• Pin count: 16
• EasyEDA symbol UUID: bc7c03bdb95e4c53b80887b7f98e1710
• EasyEDA footprint UUID: aef49373a0b14551946e29ad597a8bb4
• EasyEDA device UUID: e28ef41449c04267ad2e1ad99f73298e
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: EasyEDA property: 4.35V~6.4V.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified common connectors, power, UI, and protection seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://www.ti.com/cn/lit/gpn/bq24079t
• Product URL: https://www.ti.com/cn/lit/gpn/bq24079t
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category battery-charger, interfaces none captured, package VQFN-16-EP(3x3), and EasyEDA footprint UUID aef49373a0b14551946e29ad597a8bb4.
