TLE7259-3GE

Identity

• Manufacturer: Infineon(英飞凌)
• Model / MPN: TLE7259-3GE
• LCSC: C540020
• Category: lin-transceiver
• Description: TLE7259-3 LIN transceiver, Supply Voltage:5.5V27V, Data Rate:20Kbps, Operating Temperature:-40°C+150°C
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• lin: interface

Package And Footprint

• Package / footprint name: DSO-8
• Pin count: Unknown
• EasyEDA symbol UUID: 0d28d36f16c74571b3e54bd285128be1
• EasyEDA footprint UUID: d644c646e09c48a6becf7d148a0f43b6
• EasyEDA device UUID: 14db79a189704a92880bb8197bc6d5dc
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: Not characterized in seed; capture allowed supply rail range from datasheet.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified automotive CAN and LIN transceiver seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://atta.szlcsc.com/upload/public/pdf/source/20180112/C151500_15157256248331261431.pdf
• Product URL: https://atta.szlcsc.com/upload/public/pdf/source/20180112/C151500_15157256248331261431.pdf
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category lin-transceiver, interfaces lin, package DSO-8, and EasyEDA footprint UUID d644c646e09c48a6becf7d148a0f43b6.
