PTVS24VS1UR

Identity

Manufacturer: FUXINSEMI(富芯森美)
Model / MPN: PTVS24VS1UR
LCSC: C5380693
Category: tvs-diode
Description: PTVS24VS1UR TVS polarity:Unidirectional Reverse Stand-Off Voltage (Vrwm):24V Maximum Clamping Voltage:38.9V Peak Pulse Current (Ipp)@10/1000us:10.28A Peak Pulse Power Dissipation (Ppp)@10/1000us:400W Breakdown Voltage:26.7V Reverse Leakage Current (Ir):1uA Number of Line
Source: EasyEDA/JLC verified common component seed
Project designators: Not project-specific
Project quantity per board: Not project-specific

Capabilities

Not captured yet.

Package And Footprint

Package / footprint name: SOD-123
Pin count: Unknown
EasyEDA symbol UUID: 91666931b2c74a8c9f5705b95f229961
EasyEDA footprint UUID: 14e00bb82ab54da79822c4c0898efe45
EasyEDA device UUID: ba4458d903634d728e8881dda30b3f5c
EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

Active current: Passive part; no quiescent current.
Sleep / standby current: Passive part; no quiescent current.
Supply rails: Application-defined.
Notes: Ratings are seeded from EasyEDA/LCSC properties when present; verify against datasheet for final design.

Procurement Classification

JLC class: Extended Part
JLC note / assembly basis: EasyEDA/JLC verified automotive load-dump and transient input protection seed
Assembly status: jlc_extended
Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

Datasheet / product URL: https://atta.szlcsc.com/upload/public/pdf/source/20240115/1F327C98E07612BCEC3AECE7F1FF94CE.pdf
Product URL: https://atta.szlcsc.com/upload/public/pdf/source/20240115/1F327C98E07612BCEC3AECE7F1FF94CE.pdf
Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
Avoid when: Not captured yet.
Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
Equivalent search hints: match category tvs-diode, interfaces none captured, package SOD-123, and EasyEDA footprint UUID 14e00bb82ab54da79822c4c0898efe45.
