SN65HVD230DR

Identity

• Manufacturer: Tokmas(托克马斯)
• Model / MPN: SN65HVD230DR
• LCSC: C5342107
• Category: can-transceiver
• Description: SN65HVD230DR CAN bus transceiver; CAN Transceiver; 3V3.6V; 1Mbps; 70mA supply; 950uA quiescent; -40°C+125°C
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• can: interface

Package And Footprint

• Package / footprint name: SOP-8
• Pin count: 8
• EasyEDA symbol UUID: c70d02e8f26545a7b84f0c1f38032cb9
• EasyEDA footprint UUID: 1645372dca8547f19e87c6a19f78de2a
• EasyEDA device UUID: 4fdd7cad05e848ce9a8ee36c9ad00437
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: EasyEDA property: 70mA.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: EasyEDA property: 3V~3.6V.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified common IoT sensors, storage, and communications seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://item.szlcsc.com/datasheet/SN65HVD230DR/6116577.html
• Product URL: https://item.szlcsc.com/datasheet/SN65HVD230DR/6116577.html
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: vehicle and industrial CAN physical layer designs
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category can-transceiver, interfaces can, package SOP-8, and EasyEDA footprint UUID 1645372dca8547f19e87c6a19f78de2a.
