TM1637(TA2007)

Identity

• Manufacturer: TM(天微)
• Model / MPN: TM1637(TA2007)
• LCSC: C5337160
• Category: led-display-driver
• Description: TM1637(TA2007) dedicated LED driver/control IC
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• gpio: interface

Package And Footprint

• Package / footprint name: SOP-20
• Pin count: 20
• EasyEDA symbol UUID: 4d82411616a741c7bbd3ab401c955202
• EasyEDA footprint UUID: 878d291dc43d49c1868e27b05f308375
• EasyEDA device UUID: 259878e9294a4d4d99790f9e97776f73
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: Not characterized in seed; capture allowed supply rail range from datasheet.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified common HMI, display, audio, touch, and haptic seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://item.szlcsc.com/datasheet/TM1637(TA2007)/6103284.html
• Product URL: https://item.szlcsc.com/datasheet/TM1637(TA2007)/6103284.html
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: front-panel indicators, seven-segment displays, key-scan displays, LED matrices, and compact status dashboards
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category led-display-driver, interfaces gpio, package SOP-20, and EasyEDA footprint UUID 878d291dc43d49c1868e27b05f308375.
