TYPE-C-31-M-12A

Identity

• Manufacturer: 韩国韩荣
• Model / MPN: TYPE-C-31-M-12A
• LCSC: C5337088
• Category: usb-c-connector
• Description: TYPE-C-31-M-12A Type-C female right-angle SMT connector; 20V; 16P; 1 port; 6A power; 10,000 cycles; length 7.35mm; -30°C~+85°C
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• usb: interface

Package And Footprint

• Package / footprint name: SMD
• Pin count: Unknown
• EasyEDA symbol UUID: 62f12a6ca41f4e7f9e6fa2984061f17d
• EasyEDA footprint UUID: 69a556774be74a7ba0d824d4a42c7d7c
• EasyEDA device UUID: 5ce8248dc6724f37b3bb28946b439596
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Passive part; no quiescent current.
• Sleep / standby current: Passive part; no quiescent current.
• Supply rails: 20V
• Notes: Ratings are seeded from EasyEDA/LCSC properties when present; verify against datasheet for final design.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified common connectors, power, UI, and protection seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://item.szlcsc.com/datasheet/TYPE-C-31-M-12A/6102654.html
• Product URL: https://item.szlcsc.com/datasheet/TYPE-C-31-M-12A/6102654.html
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category usb-c-connector, interfaces usb, package SMD, and EasyEDA footprint UUID 69a556774be74a7ba0d824d4a42c7d7c.
