SM712

Identity

• Manufacturer: TECH PUBLIC(台舟)
• Model / MPN: SM712
• LCSC: C521963
• Category: rs485-esd-array
• Description: SM712 ESD polarity:Bidirectional Reverse Stand-Off Voltage (Vrwm):12V；7V Maximum Clamping Voltage:15V；25V Peak Pulse Current (Ipp):7A Peak Pulse Power Dissipation (Ppp):150W Breakdown Voltage:7.5V；13.3V Reverse Leakage Current (Ir):500nA；10nA Number of Lines:Dual c
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• rs485: interface

Package And Footprint

• Package / footprint name: SOT-23
• Pin count: Unknown
• EasyEDA symbol UUID: 6325d141a07b4bfc910b54aa892e4d1a
• EasyEDA footprint UUID: 18f92042a8ba46109ed61a02a6753de7
• EasyEDA device UUID: 13a1b67d35c441c18a3c122f0f38a9cd
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: Not characterized in seed; capture allowed supply rail range from datasheet.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified board-safety/ESD expansion seed for interfaces not yet covered (Ethernet magjack, RS-485/RS-232 bus)
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://atta.szlcsc.com/upload/public/pdf/source/20210810/E76C7C1824B0CB2A5B8963B3ABCE2DCE.pdf
• Product URL: https://atta.szlcsc.com/upload/public/pdf/source/20210810/E76C7C1824B0CB2A5B8963B3ABCE2DCE.pdf
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.
