LM66100QDCKRQ1

Identity

• Manufacturer: TI(德州仪器)
• Model / MPN: LM66100QDCKRQ1
• LCSC: C5219211
• Category: ideal-diode-controller
• Description: Automotive 1.5V to 5.5V, 1.5A, 0.5uA IQ ideal diode with integrated FET.
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• Not captured yet.

Package And Footprint

• Package / footprint name: SC-70-6
• Pin count: 6
• EasyEDA symbol UUID: cab1bb7b96214a33ac5e122d516c211f
• EasyEDA footprint UUID: 825e604db13648a48ac2bccb4482f704
• EasyEDA device UUID: e4a18f9abd7c459f840ec764627e35ff
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: Not characterized in seed; capture allowed supply rail range from datasheet.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified common power distribution, protection, and sensing seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://www.ti.com/cn/lit/gpn/lm66100-q1
• Product URL: https://www.ti.com/cn/lit/gpn/lm66100-q1
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: reverse-polarity protection, low-loss ORing, battery/adapter power-path selection, and backfeed blocking
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category ideal-diode-controller, interfaces none captured, package SC-70-6, and EasyEDA footprint UUID 825e604db13648a48ac2bccb4482f704.
