P82B96DPZ

Identity

Manufacturer: NXP(恩智浦)
Model / MPN: P82B96DPZ
LCSC: C5202507
Category: i2c-buffer
Description: Bidirectional dual 2-Wire Bus driver/buffer, 2 channels, 2V~~15V supply, 270ns delay, 7pF input capacitance, -40°C~~+85°C.
Source: EasyEDA/JLC verified common component seed
Project designators: Not project-specific
Project quantity per board: Not project-specific

Capabilities

i2c: interface

Package And Footprint

Package / footprint name: MSOP-8
Pin count: Unknown
EasyEDA symbol UUID: f28d111f64c34eee8cadaeea20ca6737
EasyEDA footprint UUID: 1bf85f8984174260ae6ed7d02d057ed4
EasyEDA device UUID: 58f831f0f5c847b4af5b2e5df00afcf3
EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

Active current: Not characterized in seed; extract active current from datasheet tables.
Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
Supply rails: EasyEDA property: 2V~15V.
Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

JLC class: Extended Part
JLC note / assembly basis: EasyEDA/JLC verified common logic, level-shifting, bus-interface, and analog-switch seed
Assembly status: jlc_extended
Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

Datasheet / product URL: https://www.nxp.com/docs/en/data-sheet/P82B96.pdf
Product URL: https://www.nxp.com/docs/en/data-sheet/P82B96.pdf
Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

Good for: longer I2C buses, mixed-voltage bus sections, hot-swap branches, stuck-bus recovery, and capacitive bus isolation
Avoid when: Not captured yet.
Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
Equivalent search hints: match category i2c-buffer, interfaces i2c, package MSOP-8, and EasyEDA footprint UUID 1bf85f8984174260ae6ed7d02d057ed4.
