LM75BTP,147

Identity

• Manufacturer: NXP(恩智浦)
• Model / MPN: LM75BTP,147
• LCSC: C5190812
• Category: temperature-sensor
• Description: LM75B high-accuracy I2C temperature sensor, ±2°C tolerance, -55°C+125°C range, 2.8V5.5V supply, 10ms conversion, 11bit resolution.
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• i2c: interface

Package And Footprint

• Package / footprint name: HWSON-8-EP(2x3)
• Pin count: Unknown
• EasyEDA symbol UUID: bfd7dfdc213c431ebbe5d6ba727592c9
• EasyEDA footprint UUID: 46157761e31f4ee482bf1e2bf149957c
• EasyEDA device UUID: 8d5c362917eb4e3aaec78c02c883e999
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: EasyEDA property: 2.8V~5.5V.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified common environment, motion, light, proximity, and temperature sensor seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://www.nxp.com.cn/docs/en/data-sheet/LM75B.pdf
• Product URL: https://www.nxp.com.cn/docs/en/data-sheet/LM75B.pdf
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: board temperature, enclosure temperature, thermal alarms, compensation inputs, and 1-Wire or I2C temperature telemetry
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category temperature-sensor, interfaces i2c, package HWSON-8-EP(2x3), and EasyEDA footprint UUID 46157761e31f4ee482bf1e2bf149957c.

Search Keywords

seed:common-sensors-environment-motion, source:easyeda-bridge, iot, common-pcb, sensors, environment, motion, lm75, temperature, i2c, thermal-monitor, temperature-sensor, hwson-8-ep-2x3, jlc-extended, jlc_extended, jlc-note:easyeda-jlc-verified-common-environment-motion-light-proximity-and-temperature-sensor-seed
