DG301-5.0-02P-14-00A(H)

Identity

• Manufacturer: DEGSON(高正/高松)
• Model / MPN: DG301-5.0-02P-14-00A(H)
• LCSC: C5128812
• Category: screw-terminal
• Description: 1x2P 5mm blue screw terminal, 1 row, 2P, 17.5A, 250V, -30°C~+120°C
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• Not captured yet.

Package And Footprint

• Package / footprint name: 插件,P=5mm
• Pin count: Unknown
• EasyEDA symbol UUID: 6a066da9bb854c5cb1a02805d0d794e3
• EasyEDA footprint UUID: 9d1274b56c7f404897a7ea6ed908dd94
• EasyEDA device UUID: 28eb66e9e2bd490caf8a7b9f998ca4c6
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Passive part; no quiescent current.
• Sleep / standby current: Passive part; no quiescent current.
• Supply rails: Application-defined.
• Notes: Ratings are seeded from EasyEDA/LCSC properties when present; verify against datasheet for final design.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified common connectors, power, UI, and protection seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://item.szlcsc.com/datasheet/DG301-5.0-02P-14-00A(H)/5733859.html
• Product URL: https://item.szlcsc.com/datasheet/DG301-5.0-02P-14-00A(H)/5733859.html
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category screw-terminal, interfaces none captured, package 插件,P=5mm, and EasyEDA footprint UUID 9d1274b56c7f404897a7ea6ed908dd94.
