VCNL4040M3OE-H3

Identity

• Manufacturer: VISHAY(威世)
• Model / MPN: VCNL4040M3OE-H3
• LCSC: C511565
• Category: proximity-sensor
• Description: VCNL4040M3OE-H3 light-intensity sensor; I2C; 2.5V3.6V; 6.553klx; 16bit; 300uA; -40°C+85°C; 4.34mm length
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• i2c: interface

Package And Footprint

• Package / footprint name: SMD-8P
• Pin count: 8
• EasyEDA symbol UUID: 00378025e254402cbc2ff167ed2a3626
• EasyEDA footprint UUID: 79b6b274a97c4db987ef54b1ffc4a295
• EasyEDA device UUID: 542207d78dc84f7db0e80726b62ea1b8
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: EasyEDA property: 2.5V~3.6V.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified common environment, motion, light, proximity, and temperature sensor seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://item.szlcsc.com/datasheet/VCNL4040M3OE-H3/526169.html
• Product URL: https://item.szlcsc.com/datasheet/VCNL4040M3OE-H3/526169.html
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: near-field object detection, gesture/proximity wake, reflective presence sensing, and IR-assisted HMI inputs
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category proximity-sensor, interfaces i2c, package SMD-8P, and EasyEDA footprint UUID 79b6b274a97c4db987ef54b1ffc4a295.
