LAN8720AI-CP-TR-ABC

Identity

• Manufacturer: MICROCHIP(美国微芯)
• Model / MPN: LAN8720AI-CP-TR-ABC
• LCSC: C510876
• Category: ethernet-phy
• Description: RMII 10/100 Ethernet PHY transceiver with HP Auto-MDIX, 10BASE-T/100BASE-TX, 10Mbit/s/100Mbit/s, 1.6V3.6V, -40°C+85°C.
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• rmii: interface
• ethernet: interface

Package And Footprint

• Package / footprint name: SQFN-24(4x4)
• Pin count: Unknown
• EasyEDA symbol UUID: fdf5b431aa7943d9b0f294d49d17066a
• EasyEDA footprint UUID: 40feb8733a43466aa042834b3ee39bef
• EasyEDA device UUID: 9c99e34536e8418e873b80d183aa2ae1
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: EasyEDA property: 1.6V~3.6V.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified common IoT sensors, storage, and communications seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://item.szlcsc.com/datasheet/LAN8720AI-CP-TR-ABC/525324.html
• Product URL: https://item.szlcsc.com/datasheet/LAN8720AI-CP-TR-ABC/525324.html
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category ethernet-phy, interfaces rmii, ethernet, package SQFN-24(4x4), and EasyEDA footprint UUID 40feb8733a43466aa042834b3ee39bef.
