ATGM336H-5NR32-G

Identity

Manufacturer: 杭州中科微
Model / MPN: ATGM336H-5NR32-G
LCSC: C49233943
Category: gnss-module
Description: ATGM336H-5NR32-G 1.8V~~3.6V UART GNSS Type:QZSS；GLONASS；BDS；GPS Interface:UART Voltage - Supply:1.8V~~3.6V Voltage - Supply:1.8V~~3.6V Current - Supply:26mA@3.3V Sensitivity:-148dBm Sensitivity:-148dBm Accuracy:2.5m Time To First Fix:32s Operating Temperature:-40℃~~+85℃ Operating Temperatur
Source: EasyEDA/JLC verified common component seed
Project designators: Not project-specific
Project quantity per board: Not project-specific

Capabilities

uart: interface

Package And Footprint

Package / footprint name: SMD,10x9.6mm
Pin count: Unknown
EasyEDA symbol UUID: d36cece3f22245398ab32dbd47a1473b
EasyEDA footprint UUID: fe9fb64a4e434a009a0a64fe1d95a9be
EasyEDA device UUID: 2d8b76ef45874b368a64ea91abc00ed2
EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

Active current: EasyEDA property: 26mA@3.3V.
Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
Supply rails: EasyEDA property: 1.8V~3.6V.
Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

JLC class: Extended Part
JLC note / assembly basis: EasyEDA/JLC verified common connectivity, positioning, and RF interface seed
Assembly status: jlc_extended
Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

Datasheet / product URL: https://item.szlcsc.com/datasheet/ATGM336H-5NR32-G/51650686.html
Product URL: https://item.szlcsc.com/datasheet/ATGM336H-5NR32-G/51650686.html
Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
Avoid when: Not captured yet.
Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
Equivalent search hints: match category gnss-module, interfaces uart, package SMD,10x9.6mm, and EasyEDA footprint UUID fe9fb64a4e434a009a0a64fe1d95a9be.
