IP5306-I2C

Identity

• Manufacturer: INJOINIC(英集芯)
• Model / MPN: IP5306-I2C
• LCSC: C488349
• Category: power-bank-soc
• Description: Highly integrated power-bank SOC, 2.1A charge, 2.4A discharge, 4.75V5.5V, I2C, 4.2V saturation, Lithium Battery, 0°C+70°C
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• i2c: interface

Package And Footprint

• Package / footprint name: ESOP-8
• Pin count: Unknown
• EasyEDA symbol UUID: 7a11eb22b99b4a368719afd8c161e701
• EasyEDA footprint UUID: 777f9cc21db645c7bacb91af74016f09
• EasyEDA device UUID: 17af21a28cd94a8896aac38de4c07a39
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: EasyEDA property: 4.75V~5.5V.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified common battery management, USB-C power, and power-path seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://item.szlcsc.com/datasheet/IP5306-I2C/497969.html
• Product URL: https://item.szlcsc.com/datasheet/IP5306-I2C/497969.html
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category power-bank-soc, interfaces i2c, package ESOP-8, and EasyEDA footprint UUID 777f9cc21db645c7bacb91af74016f09.
