HX PZ2.54-1x6P WT

Identity

• Manufacturer: hanxia(韩下)
• Model / MPN: HX PZ2.54-1x6P WT
• LCSC: C46061679
• Category: pin-header
• Description: HX PZ2.54-1x6P WT matching HX PM2.54-1x6P 1x6P 2.54mm right-angle SMT square pin header; 6P; 3A; 1kV; mating pin 6mm
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• uart: interface
• spi: interface
• gpio: interface

Package And Footprint

• Package / footprint name: SMD,P=2.54mm,卧贴
• Pin count: Unknown
• EasyEDA symbol UUID: 593e7b92552c4a2fb0980b7389beff86
• EasyEDA footprint UUID: 5b316ee1916f40efb229ebe874f1a1ed
• EasyEDA device UUID: 2246a17662cc4fbd9a33c902f7fbf252
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: Not characterized in seed; capture allowed supply rail range from datasheet.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified common connectors, power, UI, and protection seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://item.szlcsc.com/datasheet/HX%2520PZ2.54-1x6P%2520WT/48170539.html
• Product URL: https://item.szlcsc.com/datasheet/HX%2520PZ2.54-1x6P%2520WT/48170539.html
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category pin-header, interfaces uart, spi, gpio, package SMD,P=2.54mm,卧贴, and EasyEDA footprint UUID 5b316ee1916f40efb229ebe874f1a1ed.

Search Keywords

seed:common-connectors-power-ui, source:easyeda-bridge, iot, common-pcb, 2.54mm, 1x6, smd, right-angle, debug, spi, uart, pin-header, smd-p-2.54mm, jlc-extended, gpio, jlc_extended, jlc-note:easyeda-jlc-verified-common-connectors-power-ui-and-protection-seed
