74HC4051BQ,115
Identity
- Manufacturer: Nexperia(安世)
- Model / MPN: 74HC4051BQ,115
- LCSC: C455084
- Category: analog-mux
- Description: 74HC4051BQ,115
- Source: EasyEDA/JLC verified common component seed
- Project designators: Not project-specific
- Project quantity per board: Not project-specific
Capabilities
- analog: interface
- gpio: interface
Package And Footprint
- Package / footprint name: DHVQFN-16(2.5x3.5)
- Pin count: Unknown
- EasyEDA symbol UUID: 396fdd5854194371b6940061858cb53d
- EasyEDA footprint UUID: 7283904b9cda49849499f7116745a6c0
- EasyEDA device UUID: a7819decd94247f98089a405336f7d8e
- EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87
Power And Operating Modes
- Active current: Not characterized in seed; extract active current from datasheet tables.
- Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
- Supply rails: Not characterized in seed; capture allowed supply rail range from datasheet.
- Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.
Procurement Classification
- JLC class: Extended Part
- JLC note / assembly basis: EasyEDA/JLC verified common logic, level-shifting, bus-interface, and analog-switch seed
- Assembly status: jlc_extended
- Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
- Live stock: intentionally not stored as durable selection data; refresh externally before ordering.
Datasheet And Links
- Datasheet / product URL: https://item.szlcsc.com/datasheet/74HC4051BQ%252C115/457453.html
- Product URL: https://item.szlcsc.com/datasheet/74HC4051BQ%252C115/457453.html
- Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.
Selection Notes
- Good for: multiplexing analog sensors, ADC inputs, resistor ladders, and configurable measurement paths
- Avoid when: Not captured yet.
- Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
- Equivalent search hints: match category
analog-mux, interfaces analog, gpio, packageDHVQFN-16(2.5x3.5), and EasyEDA footprint UUID7283904b9cda49849499f7116745a6c0.
