E22-900M22S

Identity

Manufacturer: EBYTE(亿佰特)
Model / MPN: E22-900M22S
LCSC: C411293
Category: lora-module
Description: 868/915MHz SMT LoRa module, 2.5V~3.7V, SPI, 22.3dBm, LoRa/FSK, Stamp Hole Antenna/IPEX interface, RX 6.8mA, TX 119mA, -147dBm
Source: EasyEDA/JLC verified common component seed
Project designators: Not project-specific
Project quantity per board: Not project-specific

Capabilities

spi: interface

Package And Footprint

Package / footprint name: SMD,20x14mm
Pin count: Unknown
EasyEDA symbol UUID: 7d8c1ef39ab948e79c4dffc6ab140642
EasyEDA footprint UUID: e387697150d847709d0e21c3a04ee510
EasyEDA device UUID: 6377facb216a41b48a69d3516e3bc08f
EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

Active current: EasyEDA property: 6.8mA.
Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
Supply rails: EasyEDA property: 2.5V~3.7V.
Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

JLC class: Extended Part
JLC note / assembly basis: EasyEDA/JLC verified common connectivity, positioning, and RF interface seed
Assembly status: jlc_extended
Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

Datasheet / product URL: https://item.szlcsc.com/datasheet/E22-900M22S/402604.html
Product URL: https://item.szlcsc.com/datasheet/E22-900M22S/402604.html
Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
Avoid when: Not captured yet.
Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
Equivalent search hints: match category lora-module, interfaces spi, package SMD,20x14mm, and EasyEDA footprint UUID e387697150d847709d0e21c3a04ee510.

Search Keywords

seed:common-connectivity-positioning, source:easyeda-bridge, iot, common-pcb, e22-900m22s, sx1262, 868mhz, 915mhz, lora, ipex, lora-module, smd-20x14mm, jlc-extended, spi, jlc_extended, jlc-note:easyeda-jlc-verified-common-connectivity-positioning-and-rf-interface-seed, power
