ADM2483BRWZ
Identity
- Manufacturer: ADI(亚德诺)
- Model / MPN: ADM2483BRWZ
- LCSC: C386280
- Category: isolated-rs485-transceiver
- Description: Half-duplex iCoupler isolated RS-485 transceiver, Data Rate(Max):500Kbps, Operating Temperature:-40°C~+85°C
- Source: EasyEDA/JLC verified common component seed
- Project designators: Not project-specific
- Project quantity per board: Not project-specific
Capabilities
- uart: interface
- rs485: interface
Package And Footprint
- Package / footprint name: SOIC-16-300mil
- Pin count: 16
- EasyEDA symbol UUID: 7cac3dbc0445491cb83f54ac5757d8f2
- EasyEDA footprint UUID: 7457debad837470697cb00f57f2f939f
- EasyEDA device UUID: a41d4108a024437f9b6b845c2170adfc
- EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87
Power And Operating Modes
- Active current: Not characterized in seed; extract active current from datasheet tables.
- Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
- Supply rails: Not characterized in seed; capture allowed supply rail range from datasheet.
- Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.
Procurement Classification
- JLC class: Extended Part
- JLC note / assembly basis: EasyEDA/JLC verified industrial/machine analog I/O signal-conditioning seed
- Assembly status: jlc_extended
- Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
- Live stock: intentionally not stored as durable selection data; refresh externally before ordering.
Datasheet And Links
- Datasheet / product URL: https://item.szlcsc.com/datasheet/ADM2483BRWZ/360597.html
- Product URL: https://item.szlcsc.com/datasheet/ADM2483BRWZ/360597.html
- Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.
Selection Notes
- Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
- Avoid when: Not captured yet.
- Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
- Equivalent search hints: match category
isolated-rs485-transceiver, interfaces uart, rs485, packageSOIC-16-300mil, and EasyEDA footprint UUID7457debad837470697cb00f57f2f939f.
