A4988SETTR-T
Identity
- Manufacturer: ALLEGRO(美国埃戈罗)
- Model / MPN: A4988SETTR-T
- LCSC: C38437
- Category: stepper-driver
- Description: 2A 5.5V stepper motor driver, STEP/DIR, Control Voltage:3V~5.5V, Output Current:2A, 2 H-bridges, Step Resolution:8/2/1/16/4
- Source: EasyEDA/JLC verified common component seed
- Project designators: Not project-specific
- Project quantity per board: Not project-specific
Capabilities
- gpio: interface
Package And Footprint
- Package / footprint name: WQFN-28-EP(5x5)
- Pin count: Unknown
- EasyEDA symbol UUID: 199aea3cf5ac45288016e0bae28d765f
- EasyEDA footprint UUID: 2180c8f726be4846b4fed451e6798199
- EasyEDA device UUID: 1e558069f92b465b9016dd3192d7ec7d
- EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87
Power And Operating Modes
- Active current: Not characterized in seed; extract active current from datasheet tables.
- Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
- Supply rails: Not characterized in seed; capture allowed supply rail range from datasheet.
- Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.
Procurement Classification
- JLC class: Extended Part
- JLC note / assembly basis: EasyEDA/JLC verified common drivers, isolation, and actuation seed
- Assembly status: jlc_extended
- Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
- Live stock: intentionally not stored as durable selection data; refresh externally before ordering.
Datasheet And Links
- Datasheet / product URL: https://item.szlcsc.com/datasheet/A4988SETTR-T/39420.html
- Product URL: https://item.szlcsc.com/datasheet/A4988SETTR-T/39420.html
- Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.
Selection Notes
- Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
- Avoid when: Not captured yet.
- Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
- Equivalent search hints: match category
stepper-driver, interfaces gpio, packageWQFN-28-EP(5x5), and EasyEDA footprint UUID2180c8f726be4846b4fed451e6798199.
