0ZCF0110FF2C

Identity

• Manufacturer: belfuse
• Model / MPN: 0ZCF0110FF2C
• LCSC: C3760725
• Category: resettable-fuse
• Description: 0ZCF0110FF2C 33V 1.1A resettable fuse; max 100A; trip 2.2A; Pd 1.5W; Ri min 90mΩ; R1 max 410mΩ; trip max 500ms; -40°C~+85°C
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• Not captured yet.

Package And Footprint

• Package / footprint name: SMD,5.1x7.4mm
• Pin count: Unknown
• EasyEDA symbol UUID: d3d1d359d40e476aa1b5f80397aa2582
• EasyEDA footprint UUID: e10d6a9de1cc4acf952f26306c5c42e6
• EasyEDA device UUID: 7b806d53a57b42068017759de9e555a5
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: Not characterized in seed; capture allowed supply rail range from datasheet.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified common connectors, power, UI, and protection seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://item.szlcsc.com/datasheet/0ZCF0110FF2C/4328256.html
• Product URL: https://item.szlcsc.com/datasheet/0ZCF0110FF2C/4328256.html
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category resettable-fuse, interfaces none captured, package SMD,5.1x7.4mm, and EasyEDA footprint UUID e10d6a9de1cc4acf952f26306c5c42e6.
