ADS1115IDGSR

Identity

• Manufacturer: TI(德州仪器)
• Model / MPN: ADS1115IDGSR
• LCSC: C37593
• Category: adc
• Description: ADS111x ultra-small low-power 860SPS 16-bit I2C ADC with internal reference, oscillator and comparator, 2V~5.5V, 2 channels.
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• i2c: interface
• adc: interface

Package And Footprint

• Package / footprint name: VSSOP-10
• Pin count: Unknown
• EasyEDA symbol UUID: 070e47afc9df423a956edc6880ae6146
• EasyEDA footprint UUID: bf471488bcf94b1aa820390f51c4193d
• EasyEDA device UUID: 1b8c44c8e5f94c4bbe7cdc8bc6223b68
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: EasyEDA property: 2V~5.5V.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified common IoT sensors, storage, and communications seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://www.ti.com/cn/lit/gpn/ads1115
• Product URL: https://www.ti.com/cn/lit/gpn/ads1115
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: external precision analog measurements, differential sensor inputs, and microcontrollers with limited ADC channels
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category adc, interfaces i2c, adc, package VSSOP-10, and EasyEDA footprint UUID bf471488bcf94b1aa820390f51c4193d.
