W5500

Identity

Manufacturer: WIZNET
Model / MPN: W5500
LCSC: C32843
Category: ethernet-controller
Description: W5500 hardwired TCP/IP embedded Ethernet controller; SPI; 3.3V; 8 channels; integrated PHY; 32KB; 10BASE-T/100BASE-T; -40°C~+85°C
Source: EasyEDA/JLC verified common component seed
Project designators: Not project-specific
Project quantity per board: Not project-specific

Capabilities

spi: interface
ethernet: interface

Package And Footprint

Package / footprint name: LQFP-48(7x7)
Pin count: 48
EasyEDA symbol UUID: d467cc2b98694860a97d640a1fec1fa4
EasyEDA footprint UUID: 94e55486232b41198125948d47b100ce
EasyEDA device UUID: b031ac60524a4e6b838e8d4f8f0d98df
EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

Active current: Not characterized in seed; extract active current from datasheet tables.
Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
Supply rails: EasyEDA property: 3.3V.
Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

JLC class: Extended Part
JLC note / assembly basis: EasyEDA/JLC verified common IoT sensors, storage, and communications seed
Assembly status: jlc_extended
Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

Datasheet / product URL: https://item.szlcsc.com/datasheet/W5500/33808.html
Product URL: https://item.szlcsc.com/datasheet/W5500/33808.html
Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
Avoid when: Not captured yet.
Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
Equivalent search hints: match category ethernet-controller, interfaces spi, ethernet, package LQFP-48(7x7), and EasyEDA footprint UUID 94e55486232b41198125948d47b100ce.
