PAM8301AAF

Identity

• Manufacturer: DIODES(美台)
• Model / MPN: PAM8301AAF
• LCSC: C3001605
• Category: audio-amplifier
• Description: Filterless Class-D mono audio amplifier, 2.5V~5.5V, 1-Channel, 1.5Wx1@8Ω, Iq:4mA, SNR:78dB, PSRR:50dB, Efficiency:88%
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• Not captured yet.

Package And Footprint

• Package / footprint name: SOT-23-6
• Pin count: 6
• EasyEDA symbol UUID: 1b6af4b8cefa4578911911b62af42dca
• EasyEDA footprint UUID: ebc5370dc87d4461ad5320a48450ab14
• EasyEDA device UUID: 63c53b8007f444288fda455718cbd006
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: EasyEDA property: 2.5V~5.5V.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified common HMI, display, audio, touch, and haptic seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://item.szlcsc.com/datasheet/PAM8301AAF/3485210.html
• Product URL: https://item.szlcsc.com/datasheet/PAM8301AAF/3485210.html
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: audible alerts, speaker outputs, voice prompts, simple playback, and enclosure-mounted sound feedback
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category audio-amplifier, interfaces none captured, package SOT-23-6, and EasyEDA footprint UUID ebc5370dc87d4461ad5320a48450ab14.
