IPEX-1

Identity

Manufacturer: Ziisor(致哲)
Model / MPN: IPEX-1
LCSC: C2987682
Category: rf-connector
Description: IPEX RF Series:IPEX
Source: EasyEDA/JLC verified common component seed
Project designators: Not project-specific
Project quantity per board: Not project-specific

Capabilities

rf: interface

Package And Footprint

Package / footprint name: SMD
Pin count: Unknown
EasyEDA symbol UUID: 62bc7760f2244be3a982016ddbc106ca
EasyEDA footprint UUID: f9c6e6f2284b4016972f0f59259fbf56
EasyEDA device UUID: 3b43b7628da7418c9836cc25a6511b1b
EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

Active current: Passive part; no quiescent current.
Sleep / standby current: Passive part; no quiescent current.
Supply rails: Application-defined.
Notes: Ratings are seeded from EasyEDA/LCSC properties when present; verify against datasheet for final design.

Procurement Classification

JLC class: Extended Part
JLC note / assembly basis: EasyEDA/JLC verified common connectivity, positioning, and RF interface seed
Assembly status: jlc_extended
Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

Datasheet / product URL: https://item.szlcsc.com/datasheet/IPEX-1/3441431.html
Product URL: https://item.szlcsc.com/datasheet/IPEX-1/3441431.html
Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
Avoid when: Not captured yet.
Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
Equivalent search hints: match category rf-connector, interfaces rf, package SMD, and EasyEDA footprint UUID f9c6e6f2284b4016972f0f59259fbf56.
