MAX17055ETB+T

Identity

• Manufacturer: ADI(亚德诺)/MAXIM(美信)
• Model / MPN: MAX17055ETB+T
• LCSC: C2976422
• Category: fuel-gauge
• Description: 7uA 1-cell fuel gauge with ModelGauge m5 EZ, 2.3V~4.9V, I2C, End-Off Voltage:3.3V, Lithium Battery/LiFePO4 Battery, 1 cell
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• i2c: interface

Package And Footprint

• Package / footprint name: TDFN-10-EP
• Pin count: 10
• EasyEDA symbol UUID: 0bcdd0b3df80499580333fc6861ba8f9
• EasyEDA footprint UUID: ac6bbf303dde4c0c826ddaf4be67e977
• EasyEDA device UUID: 89d047677f2840e5ba35fc670836c3f4
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: EasyEDA property: 2.3V~4.9V.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified common connectors, power, UI, and protection seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://item.szlcsc.com/datasheet/MAX17055ETB%252BT/3382717.html
• Product URL: https://item.szlcsc.com/datasheet/MAX17055ETB%252BT/3382717.html
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category fuel-gauge, interfaces i2c, package TDFN-10-EP, and EasyEDA footprint UUID ac6bbf303dde4c0c826ddaf4be67e977.
